Product Description

Product Advantage:

Hastelloy C-276 Hastelloy, a nickel-chromium-molybdenum alloy, resistant to high temperatures and corrosion. This alloy has excellent corrosion resistance to most corrosive media in both oxidized and reduced states. Excellent resistance to pitting corrosion, crevice corrosion and stress corrosion cracking. The alloy is suitable for use in a variety of chemical process industries containing oxidizing and reducing media. The higher molybdenum and chromium content makes the alloy resistant to chloride ion erosion, and the tungsten element further improves its corrosion resistance. Hastelloy C-276 is one of the only materials resistant to corrosion by wet chlorine, hypochlorite and chlorine dioxide solutions. The alloy has significant corrosion resistance to high concentrations of chloride salt solutions (such as chlorine iron and copper chloride).

The chemical composition:

Ni

Mo

Cr

Fe

W

Co

Mn

V

C

Si

P

S

Remainder

15.0-17.0

14.5-16.5

4.0-7.0

3.0-4.5

≤2.5

≤1.0

≤0.35

≤0.01

≤0.08

≤0.04

≤0.03

Mechanical properties

tensile strength( Mpa)	0.2% yield strength ( Mpa)	Elongation A5(%)
≥690	≥283	≥40

Density: 8.87g/cm³

Material	Austenitic 300 series dual grade duplex and super duplex super austenitic stainless steel pipe tube 400 series steel for heat exchanger/condenser/semiconductor/corrosion media transport/chemical and mechanical industry & Precision tube.
Standard	GB/T, ANSI, ASTM, ASME, DIN, EN10216, JISG, GOST 9941, etc
Shape	Seamless welded Round Pipe/Tube, Plate, Sheet, Round Rod(Bar) Rectangular and square
Surface	Annealing & Pickling, Anneal, passivate, Bright Annealing (BA Finished), Electropolishing (EP), Grinding, Polish, etc.
Material Grade	300 series austenitic	304 304H 321 321H 316 316L 317 317L 347 347H 309 310S 310H 310 314 UNS S30815
	Duplex and super duplex	Duplex: 31803 UNS S31803 32205 2205 UNS S32205 32304 UNS S32304 Super duplex: 2507 32750 UNS S32750 32760 UNS S32760
	Super austenitic	AL6XN N08367 N08904 904 904L S31254 254SMO
	400 series	405 410 430 409 439 429 430Ti
	Dual grade	304/304L 304/304l 304/l 316/316L 316/316l 316/L 304/L
Specification	Pipe/Tube range	od 6.35-762mm,wt 0.51-50.8mm ,Length Typically 6096mm
Specification	Plate/Sheet range	width ≤ 2400mm,Thk≤63.5mm(for rectangular plate) Dia ≤1800mm, Thk≤63.5mm(for round plate)
Application	It is widely used in High-temperature and Electrical industry, Medical devices, Heat-exchanger, Boiler, Chemistry, Aerospace, Nuclear power, laboratory, special gas transport, semiconductor, solar and Marine seabed gas and oil transport, liquid Etc.
Material	Inconel Incoloy Monel Hastelloy Nickel Nickel alloy nickel-based alloy Steel pipe & tube for condenser /heat-exchanger/semiconductor/corrosion media transport/chemical and mechanical industry & Precision tube.
Standard	GB/T, ANSI, ASTM, ASME, DIN, EN10216, JISG, GOST 9941, etc
Shape	Round Pipe/Tube, Plate, Sheet, Round Rod(Bar) Rectangular and square
Surface	Annealing & Pickling, Anneal, passivate, Bright Annealing (BA Finished), Electropolishing (EP), Grinding, Polish, etc.
Material Grade	Inconel	Inconel600(N06600), Inconel601(N06601), Inconel625(N06625), Inconel690(N06690)
	Hastelloy	Hastelloy B3(N10675),Hastelloy C-267(N10276), Hastelloy C-22(N06022),Hastelloy G35(N06035), Hastelloy G30 (N06030)
	Monel	Monel 400(N04400)
	Incoloy	Incoloy 800 (N08800),Incoloy 800H (N08811),Incoloy825 (N08825),N08810, Incoloy718(GH4169)
	Alloy	Alloy20 (N08020),Alloy28(N08028), Alloy31(N08031)
	Nickel	N02200(Ni 200), N02201(Ni 201)
Specification	Pipe/Tube range	od 6.35-219.1mm,wt 0.71-12.7mm ,Length Typically 6096mm
Specification	Plate/Sheet range	width ≤ 2400mm,Thk≤63.5mm(for rectangular plate) Dia ≤1800mm, Thk≤63.5mm(for round plate)
Application	It is widely used in High-temperature and Electrical industry, Medical devices, Heat-exchanger, Boiler, Chemistry, Aerospace, Nuclear power, laboratory, special gas transport, semiconductor, solar and Marine Etc.
Payment terms	1)30% deposit,the balance against copy of B/L by T/T. 2) 30% deposit by T/T, the balance by irrevocable L/C at sight.
Delivery time	Delivery time: about 2 Months
Samples	Free samples are provided for that length less than 350mm but the freight is borne by the buyer, but we permit to return to buyer after order placed.

Product Application

petroleum, chemical industry.
machinery, energy ( power plants and nuclear power, as well as onshore, offshore deep well and ultra-deep well oil and gas field development, etc.).
industry and environmental protection (such as flue gas desulfurization).
ocean development (seawater desalination, ocean engineering).
