N06601 (commonly known by commercial name Inconel 601) is a high-performance nickel-chromium-iron solid solution strengthening alloy, with its core advantages being outstanding oxidation resistance, high-temperature strength and carburization resistance.
It is mainly applied in harsh high-temperature oxidation scenarios, with typical fields including: heat treatment industry (radiant tubes, muffle tanks, furnace rollers, high-temperature fixtures); Petrochemical and chemical engineering (ethylene cracking furnace tubes, conversion furnace components, burners); Electricity and Environmental protection (gas turbine combustion chamber components, waste incinerator assemblies, heat exchangers) Aerospace (combustion chamber lining, tail nozzle); Glass and ceramic manufacturing (High-temperature kiln components) Nuclear power (high-temperature gas-cooled reactor heat exchange pipeline). Its comprehensive performance makes it the preferred material for key high-temperature structures exposed to strong oxidizing atmospheres above 1100°C for a long time.
The chemical composition:
C | Si | Mn | Al | S | Ni | Cr | Fe | Cu |
≤0.10 | ≤0.5 | ≤1.0 | 1.0-1.7 | ≤0.015 | 58.0-63.0 | 21.0-25.0 | remainder | ≤1.0 |
Mechanical properties
tensile strength( Mpa) | 0.2% yield strength ( Mpa) | Elongation A5(%) | |
≥552 | ≥207 | 30 |
Density: 8.1g/cm3
N06601 (commonly known by commercial name Inconel 601) is a high-performance nickel-chromium-iron solid solution strengthening alloy, with its core advantages being outstanding oxidation resistance, high-temperature strength and carburization resistance.
It is mainly applied in harsh high-temperature oxidation scenarios, with typical fields including: heat treatment industry (radiant tubes, muffle tanks, furnace rollers, high-temperature fixtures); Petrochemical and chemical engineering (ethylene cracking furnace tubes, conversion furnace components, burners); Electricity and Environmental protection (gas turbine combustion chamber components, waste incinerator assemblies, heat exchangers) Aerospace (combustion chamber lining, tail nozzle); Glass and ceramic manufacturing (High-temperature kiln components) Nuclear power (high-temperature gas-cooled reactor heat exchange pipeline). Its comprehensive performance makes it the preferred material for key high-temperature structures exposed to strong oxidizing atmospheres above 1100°C for a long time.
The chemical composition:
C | Si | Mn | Al | S | Ni | Cr | Fe | Cu |
≤0.10 | ≤0.5 | ≤1.0 | 1.0-1.7 | ≤0.015 | 58.0-63.0 | 21.0-25.0 | remainder | ≤1.0 |
Mechanical properties
tensile strength( Mpa) | 0.2% yield strength ( Mpa) | Elongation A5(%) | |
≥552 | ≥207 | 30 |
Density: 8.1g/cm3
