316L (UNS S31603) is an ultra-low carbon molybdenum-reinforced austenitic stainless steel, with its core advantage lying in its excellent corrosion resistance. Its composition is based on 304 stainless steel with 2-3% molybdenum added, significantly enhancing its resistance to chlorides, seawater and various organic/inorganic acids.
Mainly applied in highly corrosive environments: chemical equipment; Marine engineering Medical implants; Food and pharmaceuticals Energy; Architecture. Its balanced corrosion resistance, machinability and cost make it the preferred choice for general-purpose corrosion-resistant stainless steel in chloride ion environments, but higher-grade alloys need to be selected for high-temperature environments with high concentrations of chlorides.
The chemical composition
C | Si | Mn | S | Ni | Cr | P | Mo |
≤0.035 | ≤1.00 | ≤2.00 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | ≤0.045 | 2.00-3.00 |
Mechanical properties
tensile strength( Mpa) | yield strength ( Mpa) | Elongation A5(%) | |
≥485 | ≥170 | ≥35 |
Density: 7.98g/cm3
316L (UNS S31603) is an ultra-low carbon molybdenum-reinforced austenitic stainless steel, with its core advantage lying in its excellent corrosion resistance. Its composition is based on 304 stainless steel with 2-3% molybdenum added, significantly enhancing its resistance to chlorides, seawater and various organic/inorganic acids.
Mainly applied in highly corrosive environments: chemical equipment; Marine engineering Medical implants; Food and pharmaceuticals Energy; Architecture. Its balanced corrosion resistance, machinability and cost make it the preferred choice for general-purpose corrosion-resistant stainless steel in chloride ion environments, but higher-grade alloys need to be selected for high-temperature environments with high concentrations of chlorides.
The chemical composition
C | Si | Mn | S | Ni | Cr | P | Mo |
≤0.035 | ≤1.00 | ≤2.00 | ≤0.03 | 10.0-14.0 | 16.0-18.0 | ≤0.045 | 2.00-3.00 |
Mechanical properties
tensile strength( Mpa) | yield strength ( Mpa) | Elongation A5(%) | |
≥485 | ≥170 | ≥35 |
Density: 7.98g/cm3
